CLZ 系列船用立式離心泵具有體積小、重量輕、自吸性能好；安裝、使用方便等特點。適用于各種艦船作艙底泵、壓載泵、消防泵、冷卻泵及其它裝置配套使用。輸送介質(zhì)溫度不高于80℃。

本系列泵可按照顧客要求加裝旋液分離器，分離器將泵高壓端的介質(zhì)進行分離凈化，分離凈化后的液體引入密封腔內(nèi)對機械密封磨擦副進行沖洗和冷卻，避免介質(zhì)中的顆粒物磨損磨擦副，使機械密封的壽命得以提高。

    泵的進出口法蘭符合國際GB9113.3-1988(PN1.6MPa)和GB2505-89 (PN1.6MPa船用鑄銅法蘭)。如用戶需配套其它標準法蘭應在訂貨合同中注明。

CLZ series marine vertical centrifugal pumps have the characteristics of small

 volume，tight weight，self-suction performance being nice as well as being handy of installation and operation．They are suitable for being used as bilge pumps，ballast pumps，fire pumps，cooling pumps and used for other apparatus．The max．temperature of the media transferred should not exceed 80℃．

CLZ series pump can de connected to a wet cyclone according to the requirement of the customer．The wet cyclone will separate and purify the liquid flowing from pump’s outlet The separated and purified，liquid being led to the sealed space will flush away and cool down the friction point of mechanical sealing，avoiding particles m the liquid enlarge the wear-down of the friction point and promote the life-span of the mechanical sealing．

The flange of pump’s inlet and outlet accords with the standards of GB9113.3-1988

(PN1.6Mpa)and GB2505-89(PN1.6Mpa,Marine Cast Bronze Flange)．Please make a note in the，ordering contract when the standard of the flange of pump’s inlet and outlet being differ from that above-mentioned．
